Showroom Panel STUDIO Series — UV-Printed LED Display

UV-Printed Large-Format Showroom Display — Custom Graphics, Backlit

Showroom Panel STUDIO Series

The Showroom Panel STUDIO Series brings EOS’s large-format display power together with UV-printed graphic capability. Using advanced UV flatbed digital printing, custom artwork is applied directly to the panel surface with photographic-quality color accuracy, durability, and even light diffusion — turning the showroom’s biggest display surface into a luminous branded canvas.

Designed to impress across cars, trucks, vans, and other large-scale objects, it delivers even, wide-ranging illumination as a complete EOS solution — ready to install with no additional assembly, wiring, or hassle. No minimum order on custom artwork.

Downloads:

Find Your Local Rep Now

Showroom Panel STUDIO Series Features

UV-Printed Custom Graphics

UV flatbed digital printing applies any custom design directly to the panel surface — photographic-quality image reproduction with even LED backlighting behind it. No minimum order on custom artwork.

Applications

Made for branded showpiece environments. Ideal for auto dealerships, trade shows, retail and commercial gallery displays, interior custom art displays, hospitality and experiential environments, and commercial interiors.

Slim Large-Format Profile

3.6″ (90mm) profile with LEDs along the perimeter. Maximum size 118.125″ × 240″ (240″ length × 120″ width) — inquire for larger custom sizes. Surface or pendant mount, indoor rated. Suspension via steel cable, aluminum channel, and attachment ring. On-site assembly required for sizes over 120″ × 80″.

Wide Color Range & High CRI

Dedicated White, Tunable White, RGB, or RGBW backlighting behind the printed graphic. 90+ CRI standard, with 95+ Premium CRI available for the most color-critical imagery. 24VDC standard with UNV 120–277 driver. Dimmable via 0–10V, ELV, DMX/DALI, plug-in and dimmable plug-in supplies.

Low Power Consumption & Long Life

24VDC standard (UNV 120–277 driver). Over 50,000 hours of LED lifetime — nearly 12 years at 12 hours a day — virtually maintenance-free once installed. 5-year warranty per EOS policy.

Note: lifetime and warranty inherited from the EOS platform baseline (shared 3.6″ / 24VDC / FABRIK chassis) — confirm final figures before publish.

UL Listed & Certified

UL listed for architectural applications; UL recognized for signage. All power supplies UL/ETL listed. c(UL)us Low Voltage Luminaire E480527 · c(UL)us E467626 · CE · RoHS. Standard trim: black powder-coated aluminum; unfinished and custom color trim available.
